The European-style crane end beam is a type of lifting machinery that is horizontally supported on the tracks at both ends of the factory building, capable of lifting and lowering. The hoisting trolley can run along the load of the main beam, and the main beam can run longitudinally along the tracks on both sides, using the space beneath to lift materials. There are two end beams in a bridge crane, which are respectively installed at both ends of the main beam to support the bridge frame in running overhead. They are usually made of steel materials such as Q235B.
1.It adopts rectangular tubes as the main material, featuring an elegant appearance, excellent structure, light weight and high strength.
2. The sawing machine is used for cutting, the combined machine tool for boring holes, and the CNC cutting machine for cutting holes to ensure the accuracy of the end beams.
3. The wheels are made of 45# steel through forging, undergo heat treatment, turn black, and are equipped with Chinese bearings.
4. The drive motor is a two-in-one device with electromagnetic brakes, featuring low noise, low power consumption, low maintenance rate, and a lightweight design. The motor voltage ranges from 380V to 440V and can be customized according to customer requirements.
5. The buffer is made of rubber and can withstand multiple impacts without damage.
6. It includes the photoelectric limit switch developed by our company, which can automatically cut off the power supply at a distance of one meter from the obstacle, and the crane will automatically stop running.
7. The end beam sealing plates of the European-style crane are made by die stamping and galvanized, presenting a beautiful appearance that will not rust.
8. Positioning pins are set above the end beams to ensure that the connection between the end beams and the main beams does not move.
9. The entire set of end beams includes wheels, motors, bolts, sealing plates, buffers, etc.
10. Suitable for the traveling systems of European single-girder cranes, European double-girder cranes and European gantry cranes
